RFID+AM Pedestal SYSTEM – PG530A

Short Description:

This stand-alone AM+RFID combo security gate integrates acoustic magnetic and RFID dual detection technology. It effectively identifies EAS tags and RFID labels to prevent retail theft, featuring high sensitivity, stable performance and sleek slim housing for supermarkets, boutiques and shopping malls.

Send email to us

info@etagtron.com

008615301912960 DATASHEET

Product Detail

Product Tags

AM+RFID Pedestal SYSTEM

General Descriptions

2-in-1 stand retail anti-theft system combining AM & RFID functions. Detects both traditional AM security tags and RFID chips, reliable loss prevention solution for all retail scenarios.

Technical parameters

RF Chip	Using the industry-leading Impinj E710 chip
Antenna	Adopting dual industrial grade high gain high-performance antennas
Size	H 1521mm W 305mm T 158mm(Acrylic T 20mm)
Weight	Master 18KG/pc,Slave 15KG/pc
Voltage	AC220V
Power	<50W
Operating Temperature	-10°℃-+50°℃
Storage Temperature	-20°℃-+70°℃
Operating Humidity	10%-90%

RFID Main Parameters

Detection Distance	1.8 meters (actual installation detection distance for the gate)
Tag Reading Performance	The tag reading distance range is wide,adjustable from 10cm to 2 meters, to adapt to different application scenarios. Multi-tag identification capability: >5O tags; tag identification Speed:>50 tags/second
Supported Protocols	ISO 18000-6C/EPCGIobalC1G2
Supported Frequency Bands	FCC，902~928MHz CCC，920~925MHz
Data Interface	RJ45
